Icecore quality control. TECs performance and acceptance test

ALL of manufactured TECs pass full monitoring and testing after each batch production including:

Direct TEC parameter testing

1. Elecrical parameters check up - AC resistance, Rac

2. Figure of merit, Z

3. Max temperature diffrence, DT max

4. Polarity testing

Visual Inspection

Full batch visual inspection together with direct parameters testing allows to define and reject all defective TEC in each batch.

Selective control - 10% of each batch but not less 10 pcs.

Geometry dimensions control

random tests gives the basis for the acceptance of the batch. If at least one tested sample does not meet TEC documentation, the entire batch is subjected to full verification, and all TECs that do not meet the requirements are rejected.

Temperature cycling test/Climate shock test

The temperature cycling test is conducted using the temperature shock chamber -40°C for the cold zone and +85°C for hot zone. Each batch endures 50 cycles not less 10 min each. This test indicates TEC endurance to temperature cycling.

High temperature storage 125C (accelerated aging test)

The purpose of this test is to determine the durability of the TEC at elevated ambient temperatures. Prolonged exposure to high temperatures can be a trigger for accelerated aging of module elements in the event of assembly or component defects. The module is placed in a chamber at a temperature of +125°C for 100 hours. After the tests are completed, repeated measurements of the module properties are performed and compared with the measurements before the tests.

TEC failure criteria for selective control

The recommended failure criteria for reliability tests, based on both the GR- 468-CORE recommendations and TEC operational experience, are as follows:

Change in the TEC's resistance to alternating current Rac by 5% or more;

Change in TEC efficiency Z by 5% or more;

Deviation of the TEC operating parameters from the established tolerances.

Dr. Skipidarov is the Science and technology consultant of Ice Core company. Author of the various patents in the field of commercial thermoelectric devices. Founder of the world's first thermoelectric module manufacturing company. The leading supplier of thermoelectric materials to the global market. Doctor of Sciences, Professor, author of various scientific books and works in thermoelectric industry.

Icecore maintains a quality management system to manage the processes and procedures of the product lifecycle in accordance with the requirements of the International Organization for Standardization ISO 9001.

The environmental management system and processes consistently meet the requirements of GB/T24001-2016/ISO14001:2015

The ISO GB/T24001-2016/ISO14001:2015  certification demonstrates Icecore's commitment to continuous improvement of the environmental management system, improving environmental safety and security conditions, increasing the Company's social responsibility, and reducing negative environmental impacts.

Icecore supports Occupational health and safety management activities related to the research, development and manufacturing according to GB/T45001-2020/ISO45001:2018
